MZP4 – Plug-In-Play 4 Zone All-In-One Zone Control Panel


Model: MZP4 (Plug-in-Play)

  • Universal 4 Zone Panel for Heat Pumps, Dual Fuel and Conventional 4 heat/2 cool.
  • Built in DIP switches that set desired functions for type of HVAC equipment outputs and zone thermostats used.
  • ZPS sensor to provide capacity control of the equipment.
  • Compatible with any 4/5 wire thermostats.
  • Built in LEDs indicate system status and indicators to show each zone’s call.
  • Color-coded, push-in terminal blocks makes wiring simple and fast.
  • Used with RDP, RTP, RRP, ZDSP, ZDBP & OZD Dampers
  • Also available with By-Pass Eliminator (MZP4B or MZP4BV (vertical configuration) or with Kit (MZP4BK – includes BPE, ZPS and T24 or MZP4BVK (vertical configuration)).


SKU: N/A Categories: ,


The MasterZone Control Panel is the only panel needed to provide multiple zone control of any forced air heating and cooling system. It is expandable up to ten (10) zones by adding the MZA ZONE-ADDER panels. Built-in LEDs provide continuous system operation readout and color coded screw less terminal blocks provide easy wiring. Standard single stage thermostats can be used to control two-stage and heat pump systems. Built-in second stage time or the number of zones calling brings on the second stage and the ZPS sensor provides capacity protection control for the HVAC Unit. The MZ panels have a built-in self resetting fuse to protect the transformer. Other features are zone indicator lights, adjustable heating high limit temperature for ZPS sensor, override button for time delay and a re-boot button for quick re-start.

The MZ panels operate the HVAC Unit based on a first call from any zone. Once a zone is calling for a particular mode, the MZ panels will not allow an opposite call for a maximum period of 20 minutes or possibly less based upon the time the unit was running in that mode when the opposite call was made. This “Intelligent Changeover Feature” is a unique  feature of the MZ panels.

Panels sold with BPE are connected horizontally together (MZP4 left of BPE).  For vertical configuration (MZP4 panel above BPE) select option that includes V.

MZP4 Installation & Operating Instructions
